Heating Cables

Home » Products » Heating Cables

We offer the best quality Heating Cables made of the premium quality materials. The latest technology is used in the manufacturing process of the products to mage them durable to the highest extent. The Underfloor Heating Cables are efficient enough for under-floor wiring. The Insulated Heating Cables are insulated properly to ensure total safety. That is why, we are counted among the leading Exporters of Heating Cables by supplying the products of international standard in terms quality, durability and performance.

Watts of Element	Element Length(M)	Watts/ L.M.	OHMS/M	Amps
150	12.5	11.99	28.222	0.652
250	23	10.86	9.192	1.086
275	23	11.94	8.373	1.194
380	32	11.94	4.329	1.66
500	42	11.86	2.528	2.166
750	63	12.00	1.11	3.289
1000	83	12.06	0.2820	4.353
1250	105	11.90	0.4031	0.4031
1500	125	12.00	0.2820	6.526
1750	147	11.94	0.2051	7.630
2000	167	11.95	0.1587	8.676
2250	188	11.97	0.125	9.782
2500	208	12.01	0.1018	10.858
3000	250	12.01	0.0705	13.055

Note: Tolerance in resistance upto +5% or -5% may occur.

The above elements are for voltage 230V AC

O.D. of Copper Screened & PTFE Jacketed cable: Between 2.10mm to 2.70mm (Subject to element)

O.D. of Without Sceening heating cable: 1.10mm to 1.60mm

Constructional details are as under:

Best combination of Heating wires for long life stability at the working temperatures.

PTFE Insulation (Multi-layer tape wrapped and fused) for guaranteed concentric radial thickness.

Copper wire braided screen provided maximum safety, toughness and mechanical strength

Outer PTFE (Multi-layer tape wrapped and fused) colour coded jacket.
